Stainless Steel High Pressure Triplex Plunger Pump,seawater plunger pumps 23LPM

JPCF-N

The JPCF triplex plunger pump, also called submersible pump, submersible sewage pump, 5hp water pump, electrical submersible pump, stainless steel pump, wastewater pump,
is a cold water spray plunger pump with a stainless steel pump head.
It is best for the medicine and chemical industry, seawater desalination equipment, fire fighting equipment, and other application fields.

Delivery

FOB

minimum order

1 piece

Country of Origin

NINGBO

Stock Time

10Day

Quantity

Contact Now

The JPCF triplex plunger pump, also called submersible pump, submersible sewage pump, 5hp water pump, electrical submersible pump, stainless steel pump, wastewater pump.

Duplex Stainless Steel pump

313 Stainless Steel Pump desalination of ocean water

Manifold:
2205 Stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance
Checking valve:
Stainless steel poppet valve and spring ,brass valve seat,easy to mantain
Crankcase:
Foundry& oxidation technology,biggish heat sink with good heat dissipation
Plunger:
Solid ceramic plunger
SST limit bolt/long service life
Connecting rod:
Aluminum alloy material
High load intensity,long service life
Seals:
corrosion resistant seals,increased pump performance and seal

Model	Flow		Pressure		Power		Speed	Plunger Dia	Stroke
Model	L/min	gpm	Bar	psi	hp	kw	rpm	mm	mm
JPCF1120-N24	11	2.9	200	2900	5.5	4	1450	18	10
JPCF1520-N24	15	4	200	2900	7.5	5.5	1450	18	14
JPCF1920-N24	19	5.02	200	2900	9	7.5	1450	20	14
JPCF2315-N24	23	6.08	150	2175	9	7.5	1450	22	14
JPCS1135-N24	11	2.9	350	5075	10	7.5	1450	18	10
JPCS1535-N24	15	4	350	5075	15	11	1450	18	14
JPCS1935-N24	19	5.02	350	5075	20	15	1450	20	14
JPCS2330-N24	23	6.08	300	4350	20	15	1450	22	14
