Efficient high pressure solutions for 2000bar high pressure plunger pump

Efficient high pressure solutions for the press drive high-pressure pump,2000bar high pressure plunger pump

high pressure jetting pump,Reliable descaling with powerful high pressure pump

Hydraulically driven presses work reliably and powerfully. Pressures of 300 bar and higher drive the presses. electric driven high-pressure pump are used to generate the required operating pressure. The hydraulic fluid is usually clear water or a water-oil emulsion

Manifold:

Duplex stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance

Checking valve:

Stainless steel poppet valve and spring ,brass valve seat,easy to mantain

Crankcase:

Foundry& oxidation technology,biggish heat sink with good heat dissipation

Plunger:

Solid ceramic plunger

SST limit bolt/long service life

Connecting rod:

Aluminum alloy material

High load intensity,long service life

Seals:

U-sgaoed Buna-N maerial,increased pump performance and seal Model Flow Pressure Power Speed Plunger Dia Stroke model L/min GPM bar psi HP KW rpm mm mm JPHF65 537 142 100 1450 139 102 750 65 72 JPHF70 623 165 80 1160 129 95 750 70 72 JPHS65 537 142 100 1450 139 102 750 65 72 JPHS70 623 165 80 1160 129 95 750 70 72
