High pressure pump 1500bar water jet cutter pump
JPDT
high pressure pump from 800bar to 1500bar
Delivery
FOB
minimum order
1 piece
Country of Origin
NINGBO
Stock Time
10Day
Quantity
For food application water jet cutter machinery.
| JPDT 1450RPM N VERSION 24MM SOLID SHAFT | flow jet water pump | jet pump water pump | water jet cutter pump | ||||||
| Model | Flow | Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | Bar | psi | hp | kw | rpm | mm | mm | |
| JPDT10 | 6 | 1.6 | 1500 | 21750 | 20 | 15 | 1450 | 10 | 21 |
| JPDT12 | 8 | 2.1 | 1200 | 17400 | 24 | 18.5 | 1450 | 12 | 21 |
| JPDT16 | 18 | 4.8 | 800 | 11600 | 36 | 30 | 1450 | 16 | 21 |
Application:
Manifold:
Special stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance
Checking valve:
Stainless steel poppet valve and spring ,brass valve seat,easy to mantain
Crankcase:
Foundry& oxidation technology,biggish heat sink with good heat dissipation
Plunger:
Solid ceramic plunger
SST limit bolt/long service life
Connecting rod:
Aluminum alloy material
High load intensity,long service life
Seals:
U-sgaoed Buna-N maerial,increased pump performance and seal
