JPB-C high pressure water pump
JPB-C
Designed as a popular replacement or OEM pump for many medium duty Pressure Washers, the JPB-C Series of Pumps feature a Die-Cast Anodized, Aluminum Crankcase that is Reversible for Easy Right- or Left-Hand Mounting, Hardended Stainless Steel Pistons, Solid Ceramic Plungers, Solid Brass Manifold and more. JPB Series Pumps boast a 1-Year Warranty
Delivery
FOB
minimum order
1 piece
Country of Origin
NINGBO
Stock Time
10Day
Quantity
High Pressure Triplex Plunger Pump,100bar high pressure triplex plunger pump high pressure water pump sewer jetter machine Sewer Equipment water jet pump | |||||||||
| DESCRIPTION | |||||||||
| Plunger Pumps are designed for a wide variety of moderate pressure washing applications. | |||||||||
| SPECIAL FEATURES | |||||||||
| Manifold: | |||||||||
| Forged Brass: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance | |||||||||
| Checking valve: | |||||||||
| Stainless steel poppet valve and spring ,brass valve seat,easy to mantain | |||||||||
| Crankcase: | |||||||||
| Foundry& oxidation technology,biggish heat sink with good heat dissipation | |||||||||
| Plunger: | |||||||||
| Solid ceramic plunger | |||||||||
| SST limit bolt/long service life | |||||||||
| Connecting rod: | |||||||||
| Aluminum alloy material | |||||||||
| High load intensity,long service life | |||||||||
| Seals: | |||||||||
U-sgaoed Buna-N maerial,increased pump performance and seal |
| Model | Flow | Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | Bar | psi | hp | kw | rpm | mm | mm | |
| JPB-C0510 | 5 | 1.3 | 100 | 1450 | 1.5 | 1.1 | 1450 | 18 | 5 |
| JPB-C0818 | 8 | 2.1 | 180 | 2610 | 4 | 3 | 1450 | 18 | 7 |
| JPB-C1120 | 11 | 2.9 | 200 | 2900 | 6 | 4 | 1450 | 18 | 10 |
| JPB-C1320 | 13 | 3.4 | 200 | 2900 | 7 | 5.5 | 1450 | 18 | 12 |
| JPB-C1520 | 15 | 4 | 200 | 2900 | 7.5 | 5.5 | 1450 | 18 | 14 |
| JPB-C1910 | 19 | 5 | 100 | 1450 | 5.5 | 4 | 1450 | 20 | 14 |
