JPBF corrosion resistant high pressure pump
JPBF-N
The JPBF-N triplex plunger pump, also called cleaner pump, fire fighting pump, sea pump, pressure pump, water injection pump, and stainless steel pump, is a cold water spray plunger pump with a stainless steel pump head.
It is best for the medicine and chemical industry, seawater desalination equipment, fire fighting equipment, and other application fields.
It is best for the medicine and chemical industry, seawater desalination equipment, fire fighting equipment, and other application fields.
Delivery
FOB
minimum order
1 piece
Country of Origin
NINGBO
Stock Time
10Day
Quantity
We supply corrosion resistant high pressure pump, ss water pump ,food water jetting water pump supplier.
Duplex Stainless Steel High Pressure Triplex Plunger Pump,desalination pump
| Manifold: | |||||
| duplex 2205 Stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance | |||||
| Checking valve: | |||||
| Stainless steel poppet valve and spring ,brass valve seat,easy to mantain | |||||
| Crankcase: | |||||
| Foundry& oxidation technology,biggish heat sink with good heat dissipation | |||||
| Plunger: | |||||
| Solid ceramic plunger | |||||
| SST limit bolt/long service life | |||||
| Connecting rod: | |||||
| Aluminum alloy material | |||||
| High load intensity,long service life | |||||
| Seals: | |||||
| corrosion resistant seals,increased pump performance and seal |
| Model | Flow | Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | Bar | psi | hp | kw | rpm | mm | mm | |
| JPBF-N0510 | 5 | 1.3 | 100 | 1450 | 1.5 | 1.1 | 1450 | 18 | 5 |
| JPBF-N0810 | 8 | 2.1 | 100 | 1450 | 2 | 1.5 | 1450 | 18 | 7 |
| JPBF-N1110 | 11 | 2.9 | 100 | 1450 | 3 | 2.2 | 1450 | 18 | 10 |
| JPBF-N1310 | 13 | 3.4 | 100 | 1450 | 4 | 2.2 | 1450 | 18 | 12 |
| JPBF-N1510 | 15 | 4 | 100 | 1450 | 4 | 3 | 1450 | 18 | 14 |
