JPCF3010 30L/min High Pressure Pump used in Seawater Treatment

JPCF3010-N24

The JPCF-N triplex plunger pump, also called stainless steel pump, chemical pump, high-pressure water pump, deep well water pump, pressure washer pump, sea flo pump,
is a cold water spray plunger pump with a stainless steel pump head.
It is best for the medicine and chemical industry, seawater desalination equipment, fire fighting equipment, and other application fields.

Delivery

FOB

minimum order

1 piece

Country of Origin

NINGBO

Stock Time

10Day

Quantity

Contact Now

Stainless Steel High Pressure Triplex Plunger Pump,duplex stainless steel seawater plunger pumps

JPCF3010 30L/min High Pressure Pump used in Seawater Treatment

reverse osmosis for sea waterreverse osmosis for sea water

Seawater Treatment water pump supplier

Manifold:
2205 Stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance
Checking valve:
Stainless steel poppet valve and spring ,brass valve seat,easy to mantain
Crankcase:
Foundry& oxidation technology,biggish heat sink with good heat dissipation
Plunger:
Solid ceramic plunger
SST limit bolt/long service life
Connecting rod:
Aluminum alloy material
High load intensity,long service life
Seals:
corrosion resistant seals,increased pump performance and seal

Model	Flow		Pressure		Power		Speed	Plunger Dia	Stroke
Model	L/min	gpm	Bar	psi	hp	kw	rpm	mm	mm
JPCF3010-N24	30	7.9	100	1450	7.5	5.5	1450	25	14
JPCF3510-N24	35	9.25	100	1450	9	7.5	1450	25	16.5
JPCS3010-N24	30	7.9	100	1450	7.5	5.5	1450	25	14
JPCS3510-N24	35	9.25	100	1450	9	7.5	1450	25	16.5
