JPD High Pressure Water Triplex Plunger Pump
JPD
The JPD triplex plunger pump, also called trash pump, agriculture water pump, diesel water pump, power washer pump, or concrete pump, is a cold water spray plunger pump with a brass pump head.
It is best for car washing, truck washing, floor washing, sewer washing, rust removal, concrete removal, and other applications.
It is best for car washing, truck washing, floor washing, sewer washing, rust removal, concrete removal, and other applications.
Delivery
FOB
minimum order
1 piece
Country of Origin
NINGBO
Stock Time
10Day
Quantity
We are top factory in china for pipe line cleaning pump and drain cleaning pump and pipeline dredg water pump.
High Pressure Triplex Plunger Pump,40lpm high pressure pump
Plunger Pumps are designed for a wide variety of moderate pressure washing applications.
| Forged Brass: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance |
| Checking valve: |
| Stainless steel poppet valve and spring ,brass valve seat,easy to mantain |
| Crankcase: |
| Foundry& oxidation technology,biggish heat sink with good heat dissipation |
| Plunger: |
| Solid ceramic plunger |
| SST limit bolt/long service life |
| Connecting rod: |
| Aluminum alloy material |
| High load intensity,long service life |
| Seals: |
| U-sgaoed Buna-N maerial,increased pump performance and seal |
| Model | Flow | Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | Bar | psi | hp | kw | rpm | mm | mm | |
| JPD3020 | 30 | 7.93 | 200 | 2900 | 15 | 11 | 1450 | 28 | 11 |
| JPD4020 | 40 | 10.6 | 200 | 2900 | 20 | 15 | 1450 | 28 | 15 |
| JPD5615 | 56 | 14.8 | 150 | 2175 | 20 | 15 | 1450 | 28 | 21 |
| JPD7310 | 73 | 19.3 | 100 | 1450 | 20 | 15 | 1450 | 32 | 21 |
