JPDH Brass Cylinder Plunger Pump Max Pressure 500BAR/7200PSI
JPDH
The JPDH triplex plunger pump, also called constant pressure pump, sewage pump, water pressure pump, jet pump, washing pump, or chemical pump, is a cold water spray plunger pump with a brass pump head.
It is best for car washing, truck washing, floor washing, sewer washing, rust removal, concrete removal, and other applications
It is best for car washing, truck washing, floor washing, sewer washing, rust removal, concrete removal, and other applications
Delivery
FOB
minimum order
1 piece
Country of Origin
NINGBO
Stock Time
10Day
Quantity
We are top factory for high pressure jetting plunger pump.
For Paint remove and rust remove ，
high pressure jetting pump
high pressure water pump
High Pressure Triplex Plunger Pump,500bar triplex plunger pump for shipyard
| Plunger Pumps are designed for a wide variety of moderate pressure washing applications. |
| SPECIAL FEATURES |
| Manifold: |
| Forged Brass: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance |
| Checking valve: |
| Stainless steel poppet valve and spring ,brass valve seat,easy to mantain |
| Crankcase: |
| Foundry& oxidation technology,biggish heat sink with good heat dissipation |
| Plunger: |
| Solid ceramic plunger |
| SST limit bolt/long service life |
| Connecting rod: |
| Aluminum alloy material |
| High load intensity,long service life |
| Seals: |
| U-sgaoed Buna-N maerial,increased pump performance and seal |
| Model | Flow | Pressure | Power | Speed | Plunger Dia | Stroke | |||
| L/min | gpm | Bar | psi | hp | kw | rpm | mm | mm | |
| JPDH1250 | 12 | 3.17 | 500 | 7250 | 13 | 11 | 1450 | 18 | 11 |
| JPDH1650 | 16 | 4.2 | 500 | 7250 | 20 | 15 | 1450 | 18 | 15 |
| JPDH1850 | 18 | 4.8 | 500 | 7250 | 22 | 18.5 | 1450 | 16 | 21 |
| JPDH2250 | 22 | 5.8 | 500 | 7250 | 30 | 22 | 1450 | 18 | 21 |
| JPDH2850 | 28 | 7.4 | 500 | 7250 | 35 | 30 | 1450 | 20 | 21 |
