The JPCF corrosion-resistant seawater pump

JPCF-C

TheJPCF-C triplex plunger pump, also called drain pump, dirty water pump, stainless steel pump, submersible pump, sea flo pump, fire pump,
is a cold water spray plunger pump with a stainless steel pump head.
It is best for medicine and chemical industry, seawater desalination equipment, fire fighting equipment and other application fields.

Delivery

FOB

minimum order

1 piece

Country of Origin

NINGBO

Stock Time

10Day

Quantity

Contact Now

316 Stainless Steel High Pressure Triplex Plunger Pump,reverse osmosis plunger pumps，

corrosion-resistant seawater pump，

JPCF series stainless steel pump，

30lpm duplex stainless steel pump

316 Stainless steel: Strength and no porosity equals long life. Higher hydrostatic pressures, safety, performance
Checking valve:
Stainless steel poppet valve and spring ,brass valve seat,easy to mantain
Crankcase:
Foundry& oxidation technology,biggish heat sink with good heat dissipation
Plunger:
Solid ceramic plunger
SST limit bolt/long service life
Connecting rod:
Aluminum alloy material
High load intensity,long service life
Seals:
corrosion resistant seals,increased pump performance and seal

Model	Flow		Pressure		Power		Speed	Plunger Dia	Stroke
Model	L/min	gpm	Bar	psi	hp	kw	rpm	mm	mm
JPCF1120-C28	11	2.9	200	2900	5.5	4	1450	18	10
JPCF1520-C28	15	4	200	2900	7.5	5.5	1450	18	14
JPCF1920-C28	19	5.02	200	2900	9	7.5	1450	20	14
JPCF2315-C28	23	6.08	150	2175	9	7.5	1450	22	14
JPCS1135-C28	11	2.9	350	5075	10	7.5	1450	18	10
JPCS1535-C28	15	4	350	5075	15	11	1450	18	14
JPCS1935-C28	19	5.02	350	5075	20	15	1450	20	14
JPCS2330-C28	23	6.08	300	4350	20	15	1450	22	14
